LT1999MPMS8-50#PBF 1.2 MHz 5.8mA Current Sense Amplifier 1 Circuit 8-MSOP OP Amps Buffer Amps

Name: LT1999MPMS850PBF 12 MHz 58mA Current Sense Amplifier 1 Circuit 8MSOP OP Amps Buffer Amps
Brand: Analog Devices Inc.
Price: 5.19 USD

LT1999MPMS8-50#PBF 1.2 MHz 5.8mA Current Sense Amplifier 1 Circuit 8-MSOP OP Amps Buffer Amps Manufactures

Brand Name : Analog Devices Inc.

Model Number : LT1999MPMS8-50#PBF

Certification : ISO9001

Place of Origin : China,GuangDong,ShenZhen

MOQ : >=3pcs

Price : ￥5.19

Payment Terms : T/T, D/A, L/C, D/P, Western Union,

Supply Ability : 120000 Acre/Acres per Day+pcs+2-7days

Delivery Time : 2-5days

Packaging Details : Original factory sealed packing with standard types: tube,tray,tape and reel,box,bag packing. Or request for your need.

Description : IC CURRENT SENSE 1 CIRCUIT 8MSOP

Operating Voltage : 4.5 V ~ 5.5 V

Operating Temperature : -55°C ~ 150°C

Product Status : Active

-3db Bandwidth : 1.2 MHz

Type : Current Sense

Package / Case : 8-TSSOP

Base Product Number : LT1999

Contact Now

LT1999MPMS8-50#PBF 1.2 MHz 5.8mA Current Sense Amplifier 1 Circuit 8-MSOP OP Amps Buffer Amps

PRODUCT DESCRIPTION

The LT®1999 is a high speed precision current sense amplifier, designed to monitor bidirectional currents over a wide common mode range. The LT1999 is offered in three gain options: 10V/V, 20V/V, and 50V/V. The LT1999 senses current via an external resistive shunt and generates an output voltage, indicating both magnitude and direction of the sensed current.

The output voltage is referenced halfway between the supply voltage and ground, or an external voltage can be used to set the reference level. With a 2MHz bandwidth and a common mode input range of –5V to 80V, the LT1999 is suitable for monitoring currents in H-Bridge motor controls, switching power supplies, solenoid currents, and battery charge currents from full charge to depletion.

The LT1999 operates from an independent 5V supply and draws 1.55mA. A shutdown mode is provided for minimizing power consumption. The LT1999 is available in an 8-lead SOP, an 8-lead MSOP (original pinout), or an 8-lead pinout option engineered for FMEA.

PRODUCT PROPERTIES

Product Status	Active
Amplifier Type	Current Sense
Number of Circuits	1
Output Type	-
Slew Rate	3V/µs
-3db Bandwidth	1.2 MHz
Current - Input Bias	137.5 µA
Voltage - Input Offset	500 µV
Current - Supply	5.8mA
Voltage - Supply Span (Min)	4.5 V
Voltage - Supply Span (Max)	5.5 V
Operating Temperature	-55°C ~ 150°C
Mounting Type	Surface Mount
Package / Case	8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
Supplier Device Package	8-MSOP
Base Product Number	LT1999

LT1999MPMS8-50#PBF 1.2 MHz 5.8mA Current Sense Amplifier 1 Circuit 8-MSOP OP Amps Buffer Amps

LT1999MPMS8-50#PBF 1.2 MHz 5.8mA Current Sense Amplifier 1 Circuit 8-MSOP OP Amps Buffer Amps Images
